Parameter

Specification

System Type

UHPLC

Pump

Up to 18,000 psi / 124 MPa

Flow Range

Up to 5.000 mL/min for UHPLC configuration

Injection Modes

Full Loop / Partial Loop / μL Pick-Up / FTN

Sample Capacity

Up to 216 × 1.5 mL vials

Carryover

<0.0025% under specified conditions

Column Oven

Up to 90°C

Cooling

Down to 4°C

Detector Options

UV-Vis / DAD / FLD / RID and other compatible detectors

Parameter

Maximum Pressure

18,000 psi

Pressure Equivalent

124 MPa

Application

UHPLC

Parameter

Specification

Injection Modes

Full Loop / Partial Loop / μL Pick-Up / FTN

Loop Options

10 / 20 / 50 / 100 / 1000 / 5000 μL

Standard Capacity

108 × 1.5 mL vials

High-Throughput Capacity

216 × 1.5 mL vials

Microplate Capacity

Up to 4 × 96-well plates

Preparative Configuration

80 × 5 mL vials

Carryover

<0.0025% under specified conditions

Cooling

Optional

Injection Mode

Repeatability

Full Loop

≤0.3% RSD

Partial Loop

≤0.3% RSD under specified volume conditions

μL Pick-Up

≤1.0% RSD under specified conditions

Parameter

Specification

Temperature Control

Forced-air circulation / Peltier

Heating Range

Ambient +5°C to 90°C

Cooling Range

Down to ambient −21°C

Minimum Temperature

4°C

Temperature Accuracy

±0.5°C

Temperature Stability

±0.1°C

Column Capacity

Up to 4 × 300 mm columns

Parameter

Specification

Wavelength Range

190–900 nm

Light Source

Deuterium + Tungsten lamps

Wavelength Accuracy

±0.5 nm

Wavelength Precision

±0.1 nm

Parameter

Specification

Wavelength Options

190–640 nm / 190–800 nm

Array

1024 pixels

Spectral Resolution

0.6 nm/pixel

Wavelength Accuracy

±0.6 nm

Wavelength Precision

±0.1 nm

Standard Flow Cell

12 μL, 10 mm optical path

Low-Volume Option

2 μL, 10 mm optical path

High-Sensitivity Option

12 μL, 60 mm optical path

Parameter

Specification

Excitation Range

200–750 nm or 200–900 nm

Emission Range

200–750 nm or 200–900 nm

Light Source

Xenon Lamp

Water Raman S/N

1200:1

Sampling Rate

100 Hz

Flow Cell

12 μL

Parameter

Specification

Refractive Index Range

1–1.75

Baseline Noise

<2.5 nRIU

Baseline Drift

<200 nRIU/h

Flow Cell Volume

8 μL

Maximum Flow Rate

10 mL/min

Temperature Control

30–60°C

Temperature Accuracy

±0.1°C

Function

Capability

Instrument Control

Pump, autosampler, oven and detector control

Data Acquisition

Integrated chromatographic acquisition

Data Processing

Automatic integration and data-processing algorithms

Audit Trail

Traceable operation records

User Management

Multi-level permissions

Electronic Signature

Supported

Regulatory Support

FDA 21 CFR Part 11 / GMP / GLP

Reporting

Standard and customizable reports

Maintenance Management

Consumable-life and maintenance reminders
